Best Quality Manufacturer 12000W Hybrid Inverter US Version Split Phase 12Kw 80-400V High Voltage Hybrid Inverter
Basic System Architecture
The following illustration shows basic application of this inverter.
It also includes following devices to have a Complete running system.
- Generator or Utility
- PV modules
Consult with your system integrator for other possible system architectures depending on your requirements.
This inverter can power all kinds of appliances in home or office environment, including motor type appliances such as refrigerator and air conditioner.
| Model | GSL-H-12KHV-US |
| PV Input | |
| PV Input Power | 15.6KW |
| MPPT Number | 4 |
| Start-up Voltage | 120 |
| MPPT Voltage Range | 125V-500V |
| Max PV Input Voltage | 500V |
| Single MPPT Input Current | 12A |
| Battery | |
| Max Charging/Discharging Current | 80A/80A |
| Battery Voltage Range | 85V-400V |
| Battery Capacity Range | 6.6 to 66KWH |
| Battery Type | Lithium-ion,Lead-acid |
| Communication | CAN/RS485 |
| Back-up AC Output | |
| Rated Backup Output Power | 12KVA |
| Max Backup Output Power | 15KVA 60S,18KVA 1S |
| Backup AC Output Voltage | 110-120/220-240Vac Split phase |
| AC Frequency | 50/60Hz |
| Output THDI | <2% |
| On Grid AC Output | |
| Rate AC Output Power | ±120/240V 12KVA |
| AC Output Voltage | 211~264V@240V |
| AC Output Frenquecny | 50/60Hz (45 to 54.9Hz/55 to 60Hz) |
| Power Factor | 0.8leading...0.8lagging |
| Max Output Current | 50A |
| AC Reverse Charging | Yes |
| Output THDI | <2% |
| Efficiency | |
| Max Eifficiency | >=98.2% |
| CEC Eifficiency | >=97.2% |
| General Data | |
| Output Conduit Size | 25.4mm |
| PV Input Conduit Size | 25.4mm |
| Battery Input Conduit Size | 35.4mm |
| Operating Temperature Range | -25~+60°C |
| Environment Humidity | 0-95% |
| Altitude | 0-4000M (over 2000M derating) |
| IP Rank | IP65 |
| Weight | 30KG |
| Dimension (W*H*D) | 530×660×200mm |
| Cooling | Natural Cooling |
| Noise (dB) | <29dB |
| Display | LCD |
| Communication | Modbus,RS485,WIFI,4G |
| Self-consumption At Night | <2.5W (with battery enabling <5W) |
| No Transformer | YES |
| Safety | UL1741SA all options,UL1699B,CSA22.2 |
| EMC | FCC Part 15 ClassB |
Application Scenario
Power Storage Wall- 5Kwh 7Kwh 10Kwh
Security
Backup Protection
Power storage wall is a battery that stores energy, detects outages and automatically becomes your home's energy source when the grid goes down. Unlike gasoline generators, Power storage wall keeps your lights on and phones charged without upkeep, fuel or noise. Pair with solar and recharge with sunlight to keep your appliances running for days.
Design
Modern and Compact
With easy installation and a minimalist design, Power storage wall complements a variety of home styles. The compact, all-in-one construction features versatile mounting options for indoor or outdoor spaces.
| LiFePO4 Lithium Battery Pack Spec | ||||||||
|
Energy |
Battery |
Charging Voltage |
Standard Charge Current | Max charge | Standard Discharge Current | Maximum Continuous Discharge Current |
Dimension (L×W×H) |
Weight |
|
5 KWH |
48V / 51.2V 100Ah |
54V / 58V |
20V/50A |
120A |
50A
|
300A(1S)
|
650*480*190mm |
53KG/58.5KG |
|
7 KWH |
48V / 51.2V 150Ah |
65KG/73.3KG |
||||||
|
10 KWH |
48V / 51.2V 200Ah |
85KG/96KG |
||||||
Max support 16 units parallel connection.
Ratings & Reviews
GSL ENERGY is focused on manufacturing, R&D and sales for safe Lithium battery and solutions. With the registration and certification of CE, SGS, ROHS. Striving to grow into a global leading lithium battery supplier, GSL ENERGY has been working hard on researching and developing new process technology to make our lithium battery more affordable and able to meet the rapidly growing market demands.
♦ Over 500 workers in 12000 sqm2 battery cell production and pack manufacturing base.
♦ Passing all certificates VDE, IEC62133, IEC62219, CE, UN38.3, MSDS, etc.
Through years development and experienced international sales team in Shenzhen, GSL ENERGY green solar and lithium battery products have been sold to clients all over the world.
Best Quality Manufacturer 12000W Hybrid Inverter US Version Split Phase 12Kw 80-400V High Voltage Hybrid Inverter
For more details and price, please send us an enquiry below ⇓⇓⇓
